Advanced 16-channel 1080p Mini 1U AcuSense DVR featuring Deep Learning-based Motion Detection 2.0, perimeter protection, human and vehicle classification, facial detection, H.265 Pro+ compression, and support for up to 24 IP cameras with resolutions up to 6 MP.
Technical Specifications
Perimeter Protection
Line Crossing Detection
4-ch
Intrusion Detection
4-ch
Facial Detection
Facial Detection & Capture
Face picture detection, face picture search
Motion Detection 2.0
Human / Vehicle Analysis
Deep learning-based motion detection 2.0 enabled by default for all analog channels, with human and vehicle classification to significantly reduce false alarms caused by objects such as leaves and lights
Quick Search
Quick search by object or event type
Video & Audio
IP Video Input
2-ch (up to 18-ch)
Enhanced IP Mode
8-ch (up to 24-ch), each up to 4 Mbps
IP Camera Resolution
Up to 6 MP
Supported IP Camera Compression
H.265+ / H.265 / H.264+ / H.264
Analog Video Input
16-ch BNC interfaces (1.0 Vp-p, 75 Ω), supporting Coaxitron connection
Video Input Support
HDTVI / AHD / CVI / CVBS / IP
Audio
Audio via coaxial cable
Encoding Ability
Up to 3K / 5M Lite @ 12 fps
Recording
Video Compression
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Incoming Bandwidth
96 Mbps
Network
Remote Connection
128
Total Bandwidth
128 Mbps
Key Features
Channel Capacity
16-channel 1080p Mini 1U AcuSense DVR
IP Camera Capacity
Up to 24-ch IP cameras, up to 6 MP
Motion Detection
Deep Learning-based Motion Detection 2.0
Perimeter Protection
Line Crossing Detection / Intrusion Detection
Facial Detection
Facial Detection, Capture & Face Picture Search
Target Classification
Human and vehicle classification
Video Compression
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
