High-quality 4 MP Smart Hybrid Light 3.0 Vari-Focal Dome Network Camera featuring HikAI-ISP for improved image quality, Motion Detection 3.0 for accurate person and vehicle detection, Smart Hybrid Light with IR and white lights, built-in microphone, motorized 2.8 to 12 mm varifocal lens, and IP67 dust and water resistance.
Technical Specifications
Camera
Image Sensor
1/3" Progressive Scan CMOS
Maximum Resolution
2688 × 1520
Minimum Illumination
Color: 0.003 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1 s to 1/100,000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 355°
Tilt: 0° to 75°
Rotate: 0° to 355°
Lens
Lens Type
Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV
2.8 to 12 mm: Horizontal FOV 93° to 28°, Vertical FOV 50° to 16°, Diagonal FOV 110° to 33°
Lens Mount
Ø14
Wide Dynamic Range (WDR)
120 dB
SNR
≥ 52 dB
Day/Night Mode
Day, Night, Auto, Schedule
Image Enhancement
BLC, HLC, 3D DNR
Privacy Mask
4 programmable polygon privacy masks
Smart Features
HikAI-ISP
Noise reduction, color correction, and image quality improvement
Motion Detection 3.0
Accurate person and vehicle detection with reduced false alarms
Smart Hybrid Light
Integrates IR and white lights with 3 supplemental lighting modes
Built-in Microphone
Supported for real-time audio security
Compression
H.265+
Protection
Weather Protection
IP67 dust and water resistant
High-performance 32-channel 5MP 1.5U AcuSense DVR featuring Deep Learning-based perimeter protection and Motion Detection 2.0 for all analog channels. It supports up to 32 analog cameras, up to 64 network cameras, 4 SATA interfaces, advanced H.265 Pro+ compression, up to 8 MP encoding capability, and POS-triggered recording with POS information overlay.
Technical Specifications
Perimeter Protection
Human / Vehicle Analysis
Up to 16-ch, for channel 1/2/3/4/9/10/11/12/17/18/19/20/25/26/27/28 only
Motion Detection 2.0
Human / Vehicle Analysis
Deep learning-based Motion Detection 2.0 is enabled by default for all analog channels. It can classify human and vehicle targets and significantly reduce false alarms caused by objects such as leaves and lights.
Quick Search
Quick search by object or event type is supported
Video & Audio
Analog Camera Input
Up to 32-ch analog camera inputs
Video Input Support
HDTVI / AHD / CVI / CVBS / IP
IP Video Input
32-ch (up to 64-ch)
IP Camera Resolution
Up to 12 MP
Supported IP Camera Compression
H.265+ / H.265 / H.264+ / H.264
Encoding
Encoding Capability
Up to 8 MP @ 8 fps / 5 MP @ 12 fps
Video Compression
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Recording
Video Compression
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
POS Recording
POS triggered recording and POS information overlay
Network
Remote Connection
128
Network Protocol
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP,
NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP
Storage
SATA Interfaces
4 SATA interfaces
General
Power Supply
100 to 240 VAC, 50 to 60 Hz
Form Factor
1.5U
Key Features
Channel Capacity
32-channel 5MP AcuSense DVR
Analog Camera Inputs
Up to 32-ch
Network Camera Inputs
Up to 64-ch
Perimeter Protection
Deep Learning-based Human / Vehicle Analysis up to 16-ch
Motion Detection
Deep Learning-based Motion Detection 2.0 for all analog channels
Encoding Capability
Up to 8 MP @ 8 fps / 5 MP @ 12 fps
Compression Technology
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
POS Function
POS triggered recording and POS information overlay
4-channel 1080p 1U AcuSense DVR featuring Deep Learning-based human and vehicle target classification, Motion Detection 2.0, perimeter protection, facial detection, efficient H.265 Pro+ compression, and support for up to 6 network cameras with resolutions up to 6 MP.
Technical Specifications
Perimeter Protection
Human / Vehicle Analysis Up to 2-ch
Facial Detection
Facial Detection & Capture Face picture detection, face picture search
Motion Detection 2.0
Human / Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels. It can classify human and vehicle targets and significantly reduce false alarms caused by objects such as leaves and lights.
Quick Search Quick search by object or event type
Video & Audio
Analog Video Input 4 channels
Video Input Signals HDTVI / AHD / CVI / CVBS / IP
IP Video Input 1-ch (up to 5-ch)
Enhanced IP Mode 2-ch (up to 6-ch), each up to 4 Mbps
IP Camera Resolution Up to 6 MP
Supported IP Camera Compression H.265+ / H.265 / H.264+ / H.264
Audio Audio via coaxial cable
Encoding Ability Up to 3K / 5M Lite @ 12 fps
Recording
Video Compression H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Storage
HDD 1 HDD
Key Features
Channel Capacity 4-channel 1080p 1U AcuSense DVR
Network Camera Capacity Up to 6 network cameras
Target Classification Human and vehicle target classification based on Deep Learning
Motion Detection Deep Learning-based Motion Detection 2.0
Perimeter Protection Human / Vehicle Analysis up to 2-ch
Facial Detection Facial Detection, Capture & Face Picture Search
Compression Technology H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Advanced 16-channel 1080p Mini 1U AcuSense DVR featuring Deep Learning-based Motion Detection 2.0, perimeter protection, human and vehicle classification, facial detection, H.265 Pro+ compression, and support for up to 24 IP cameras with resolutions up to 6 MP.
Technical Specifications
Perimeter Protection
Line Crossing Detection
4-ch
Intrusion Detection
4-ch
Facial Detection
Facial Detection & Capture
Face picture detection, face picture search
Motion Detection 2.0
Human / Vehicle Analysis
Deep learning-based motion detection 2.0 enabled by default for all analog channels, with human and vehicle classification to significantly reduce false alarms caused by objects such as leaves and lights
Quick Search
Quick search by object or event type
Video & Audio
IP Video Input
2-ch (up to 18-ch)
Enhanced IP Mode
8-ch (up to 24-ch), each up to 4 Mbps
IP Camera Resolution
Up to 6 MP
Supported IP Camera Compression
H.265+ / H.265 / H.264+ / H.264
Analog Video Input
16-ch BNC interfaces (1.0 Vp-p, 75 Ω), supporting Coaxitron connection
Video Input Support
HDTVI / AHD / CVI / CVBS / IP
Audio
Audio via coaxial cable
Encoding Ability
Up to 3K / 5M Lite @ 12 fps
Recording
Video Compression
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Incoming Bandwidth
96 Mbps
Network
Remote Connection
128
Total Bandwidth
128 Mbps
Key Features
Channel Capacity
16-channel 1080p Mini 1U AcuSense DVR
IP Camera Capacity
Up to 24-ch IP cameras, up to 6 MP
Motion Detection
Deep Learning-based Motion Detection 2.0
Perimeter Protection
Line Crossing Detection / Intrusion Detection
Facial Detection
Facial Detection, Capture & Face Picture Search
Target Classification
Human and vehicle classification
Video Compression
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
```
The DS-2XS3Q47G1-LDH/4G/C18S40 is a 4 MP ColorVu solar-powered security PT camera setup designed for reliable 24/7 colorful imaging. It features a standalone solar panel with built-in battery, efficient H.265+ compression, built-in two-way audio, and 4G LTE communication for real-time security monitoring.
Technical Specifications
Key Features
Product Model
DS-2XS3Q47G1-LDH/4G/C18S40
Product Type
4MP ColorVu Solar-powered Security PT Camera Setup
Image Resolution
4 MP
Power Solution
Standalone solar panel with built-in battery
Color Imaging
24/7 colorful imaging
Compression Technology
H.265+
Audio
Built-in two-way audio
Communication
4G (LTE-TDD / LTE-FDD / TD-SCDMA)
Camera
Image Sensor
1/3" Progressive Scan CMOS
Max. Resolution
2688 × 1520
Min. Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
Shutter Time
1/3 s to 1/100,000 s
Day & Night
24/7 color imaging
Angle Adjustment
Solar panel: Pan: 0° to 358°, Tilt: -40° to 0°
Camera: Pan: 0° to 340°, Tilt: -5° to 105°
Lens
Lens Type
Fixed focal lens, 4 mm and 6 mm optional
Iris Type
Fixed
Aperture
F1.0
Depth of Field
4 mm: 2.7 m to ∞
6 mm: 5.9 m to ∞
Focal Length & FOV
4 mm: Horizontal FOV: 75°, Vertical FOV: 40°, Diagonal FOV: 89°
6 mm: Horizontal FOV: 49°, Vertical FOV: 27°, Diagonal FOV: 57°
Lens Mount
M12
High-quality 2 MP ColorVu Fixed Turret Network Camera delivering 24/7 colorful imaging with excellent low-light performance. Features H.265+ compression, 120 dB WDR, deep-learning-based human and vehicle classification, built-in microphone, 30 m white light illumination, and IP67 water and dust resistance.
Technical Specifications
Key Features
Product Model
DS-2CD2327G2-LU 2MP
Product Type
2 MP ColorVu Fixed Turret Network Camera
Resolution
2 MP
Compression Technology
H.265+ / H.265 / H.264+ / H.264
WDR
120 dB
Smart Classification
Human and Vehicle Classification based on Deep Learning
Built-in Microphone
Yes (-U)
Color Imaging
24/7 Colorful Imaging
Weather Protection
IP67 Water and Dust Resistant
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter Time
1/3 s to 1/100,000 s
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 75°
Rotate: 0° to 360°
Lens
Lens Type
Fixed Focal Lens, 2.8 mm / 4 mm Optional
Focal Length & FOV
2.8 mm: H: 107°, V: 56°, D: 127°
4 mm: H: 84°, V: 45°, D: 99°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
Depth of Field
2.8 mm: 1.7 m to ∞
4 mm: 2.3 m to ∞
DORI
2.8 mm
D: 46 m, O: 18 m, R: 9 m, I: 4 m
4 mm
D: 56 m, O: 22 m, R: 11 m, I: 5 m
Illuminator
Supplement Light Type
White Light
Supplement Light Range
30 m
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Third stream is supported under certain settings.
Video Compression
Main Stream: H.265 / H.264 / H.264+ / H.265+
Sub-Stream: H.265 / H.264 / MJPEG
Third Stream: H.265 / H.264
Third stream is supported under certain settings.
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile / Main Profile / High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR / VBR
Scalable Video Coding (SVC)
H.264 and H.265 Encoding
Region of Interest (ROI)
1 Fixed Region for Main Stream and Sub-Stream
Audio
Audio Compression
-U: G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw / G.711alaw)
16 Kbps (G.722.1)
16 Kbps (G.726)
32 to 192 Kbps (MP2L2)
8 to 320 Kbps (MP3)
16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
-U: 8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
Environment Noise Filtering
-U: Yes
High-performance S Series NVR with AcuSense, supporting up to 64 IP cameras,
up to 32 MP resolution, 1 Gbps incoming bandwidth, 800 Mbps outgoing bandwidth,
up to 32-channel 1080p decoding, intelligent analytics, facial recognition,
perimeter protection, video structuralization, AcuSearch, RAID storage protection,
and HDMI video output up to 8K resolution.
Technical Specifications
Intelligent Analytics
AI by NVR
Facial recognition, perimeter protection, video structuralization
AI by Camera
Facial recognition, perimeter protection, video structuralization,
AcuSearch, Motion Detection 2.0, ANPR, people counting, VCA
AcuSearch by Camera
All channels, up to 345,600 targets per day
AcuSearch Note
The camera should enable AcuSearch function
Perimeter Protection
By NVR - Simultaneous Mode
8-ch, up to 2 MP
By NVR - Independent Mode
4-ch, up to 2 MP
By Camera
All channels
Video Structuralization
Structured Analysis - Simultaneous Mode
8-ch, up to 2 MP
Structured Analysis - Independent Mode
4-ch, up to 2 MP
Facial Recognition
Facial Detection and Analytics
Face picture comparison, human face capture, face picture search
Face Picture Library
Up to 64 face picture libraries, with up to 300,000 face pictures
in list library. Each picture ≤ 4 MB, total capacity ≤ 10 GB
Face Picture Comparison
16-ch; comparison speed: 24 pictures per second
Face Picture Comparison (Captured from Camera)
16-ch; comparison speed: 24 pictures per second
Facial Detection and Analytics Performance
Simultaneous mode: 8-ch, up to 2 MP;
Independent mode: 4-ch, up to 2 MP
Video and Audio
IP Video Input
64-ch
Maximum IP Video Resolution
Up to 32 MP
IP Camera Capacity
Up to 64-ch IP cameras
IP Speakers
Up to 8-ch IP speakers
Decoding
Decoding Capacity
Up to 32 × 1080p
Video Compression
H.265+ / H.265 / H.264+ / H.264
Network
Incoming Bandwidth
Up to 1 Gbps
Outgoing Bandwidth
Up to 800 Mbps
IP Camera Connections
Up to 64-ch IP cameras
Video Output
HDMI Video Output
Up to 8K resolution
Storage
RAID Support
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Hot Spare
N+M hot spare
Storage Protection
RAID and N+M hot spare technology provides reliable data storage
and helps reduce data loss risks
General
Model
DS-9664NXI-S8
Series
S Series NVR with AcuSense
Maximum IP Camera Inputs
Up to 64-ch
Maximum Resolution
Up to 32 MP
Maximum Decoding
Up to 32 × 1080p
AI Features
Facial recognition, perimeter protection, video structuralization,
AcuSearch, Motion Detection 2.0, ANPR, people counting, and VCA
HDMI Output
Up to 8K resolution
IP Speakers
Up to 8-ch
High-performance 128-channel 3U 8K NVR designed for professional surveillance systems, supporting up to 128 IP camera inputs, up to 32 MP resolution, 400 Mbps incoming and outgoing bandwidth, 8K video output, advanced streaming technology, RAID storage protection, specialist camera support, redundant power supply, and up to 8-channel IP speakers.
Technical Specifications
Video and Audio
IP Video Input
128-ch
Maximum IP Video Resolution
Up to 32 MP
High-Resolution IP Inputs
Up to 8-ch 32/24/16 MP IP video inputs
Incoming Bandwidth
400 Mbps
Outgoing Bandwidth
400 Mbps
IP Speakers
Up to 8-ch IP speakers
Specialist Camera Support
People counting cameras, ANPR (Automatic Number Plate Recognition) cameras, and fisheye cameras
Streaming Technology
Advanced streaming technology enables smooth live view in poor network conditions
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output
2-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Video Output
HDMI 1 Output
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz,
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz,
1920 × 1080/60Hz, 1600 × 1200/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
HDMI 2 Output
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz,
2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz,
1600 × 1200/60Hz, 1280 × 1024/60Hz,
1280 × 720/60Hz, 1024 × 768/60Hz
HDMI Output Limitation
When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p
VGA 1 Output
1920 × 1080/60Hz, 1280 × 1024/60Hz,
1280 × 720/60Hz, 1024 × 768/60Hz
VGA 2 Output
1920 × 1080/60Hz, 1280 × 1024/60Hz,
1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode
HDMI 1 and VGA 1 provide simultaneous video output and work as the main output;
HDMI 2 and VGA 2 provide simultaneous video output and work as the auxiliary output
CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution:
PAL: 704 × 576, NTSC: 704 × 480
Decoding
Decoding Capacity
Up to 40 × 1080p @ 30fps
Video Compression
H.265+ / H.265 / H.264+ / H.264
Network
IP Camera Connections
Up to 128-ch IP cameras
Incoming Bandwidth
400 Mbps
Outgoing Bandwidth
400 Mbps
Network Performance
Advanced streaming technology enables smooth live view in poor network conditions
Special Camera Support
People counting cameras, ANPR cameras, and fisheye cameras
Storage
RAID Support
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Hot Spare
N+M hot spare
Storage Protection
RAID and N+M hot spare technology provides reliable data storage and helps reduce data loss risks
General
Model
DS-96128NI-M16/R
NVR Type
128-ch 3U 8K NVR
Maximum IP Camera Inputs
Up to 128-ch
Maximum Decoding Capacity
Up to 40 × 1080p @ 30fps
Video Outputs
2 × HDMI (different source) and 2 × VGA (different source)
Maximum Video Output
8K or dual 4K
Redundant Power Supply
Supported
Professional 32-channel 2U 4K AcuSense NVR featuring intelligent deep-learning analytics, advanced facial recognition, perimeter protection, AcuSearch, and Motion Detection 2.0. Supports up to 32 IP camera inputs, 320 Mbps incoming bandwidth, up to 32-channel 1080p decoding, and advanced AI-powered security analytics for accurate human and vehicle detection.
Technical Specifications
Video and Audio
NVR Type
32-ch 2U 4K AcuSense NVR
IP Video Input
Up to 32-ch
Incoming Bandwidth
Up to 320 Mbps
Decoding Capability
Up to 32-ch 1080p
Video Compression
H.265+ / H.265 / H.264+ / H.264
Intelligent Analytics
AI by NVR
Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch
AI by Camera
Facial recognition, perimeter protection, video structuralization,
throwing objects from building, Motion Detection 2.0, ANPR,
people counting, VCA
AI Engine
1 engine; engine mode is adjustable
AcuSearch
AcuSearch Support
Supports AcuSearch on all channels when cameras support Hikvision AcuSense Technology and AcuSearch is enabled
AcuSearch Performance
Capable of modeling up to 300,000 targets per day
Perimeter Protection
By Camera
All channels
By NVR
4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarms
Perimeter Rules
Up to 12 rules in total
Perimeter Protection Capacity
Up to 4-ch
Facial Recognition
Facial Recognition for Video Stream
Up to 4-ch
Facial Recognition for Face Picture
Up to 8-ch
Face Detection and Analytics
Face picture comparison, human face capture, face picture analytics
Face Picture Libraries
Up to 16 face picture libraries with up to 50,000 face pictures in total
Face Picture Size
Each picture ≤ 512 KB; total capacity ≤ 1 GB
Facial Detection and Analytics Performance
4-ch human face capture with HD network cameras, up to 8 MP, H.264/H.265
Face Picture Comparison
8-ch
Motion Detection 2.0
By Camera
All channels
By NVR
All channels for Hikvision cameras
Target Recognition
Human & Vehicle Recognition
Intelligent human and vehicle recognition based on deep learning algorithms
Deep Learning Analytics
Intelligent analytics based on deep learning algorithm
General
Model
DS-9632NXI-I8/S
NVR Type
32-ch 2U 4K AcuSense NVR
Maximum IP Camera Inputs
Up to 32-ch
Maximum Decoding Capacity
Up to 32-ch 1080p
AI Technology
Deep Learning / AcuSense
6 MP Smart Hybrid Light Motion 2.0 Motorized Varifocal Bullet Network Camera designed for reliable indoor and outdoor surveillance. It delivers high-quality 6 MP imaging, Human and Vehicle Detection, long-range Smart Hybrid Light, efficient H.265+ compression, 120 dB WDR, 3D DNR, built-in microphone, motorized varifocal lens, onboard storage up to 512 GB, and IP67/IK10 protection.
Technical Specifications
Camera
Model
DS-2CD3661G2-LIZSU(2.7-13.5mm)(O-STD)
Image Sensor
1/2.4" Progressive Scan CMOS
Maximum Resolution
3200 × 1800
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
Detection
Human and Vehicle Detection
Lens
Lens Type
Varifocal lens, motorized lens, 2.7 to 13.5 mm
Focal Length & FOV
2.7 to 13.5 mm
Horizontal FOV: 106° to 35.6°
Vertical FOV: 55.9° to 20°
Diagonal FOV: 127.4° to 40.8°
Lens Mount
Ø14
Iris Type
Fixed
Aperture
Max. F1.6
Depth of Field
Wide: 1 m to ∞
Tele: 4 m to ∞
DORI
Wide
D: 68.1 m, O: 27 m, R: 13.6 m, I: 6.8 m
Tele
D: 200 m, O: 79.4 m, R: 40 m, I: 20 m
Illuminator
Supplement Light Type
IR, White Light
Supplement Light Range
Up to 50 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
Video
Main Stream
50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 1 fps (640 × 360)
60 Hz: 1 fps (640 × 360)
Video Compression
Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub-Stream: H.265 / H.264 / MJPEG
Third Stream: H.265 / H.264
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile, Main Profile, High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR, VBR
Region of Interest (ROI)
1 fixed region for main stream and sub-stream
Audio
Audio Type
Mono sound
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz / 16 kHz
Audio Compression
G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw) /
16 Kbps (G.722.1) /
16 Kbps (G.726) /
32 to 160 Kbps (MP2L2) /
16 to 64 Kbps (AAC-LC)
Storage
On-board Storage
Up to 512 GB
Storage Interface
SD Card Slot
Key Features
Resolution
6 MP
Smart Hybrid Light
IR + White Light with long-range illumination
Motion Detection
Motion 2.0
Human & Vehicle Detection
Supported
Lens
Motorized Varifocal, 2.7 to 13.5 mm
Audio
Built-in Microphone for real-time audio security
Wide Dynamic Range
120 dB WDR
Noise Reduction
3D DNR
Protection
Water & Dust Resistance
IP67
Vandal Resistance
IK10
High-quality 2MP AcuSense Fixed Turret Network Camera with excellent low-light performance powered by DarkFighter technology. Features 120 dB True WDR, deep-learning-based human and vehicle classification, H.265+ compression, advanced streaming technology, IR illumination up to 40 m, and IP67 water and dust resistance.
Technical Specifications
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.002 Lux @ (F1.4, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV (2.8 mm)
Horizontal FOV: 107°
Vertical FOV: 57°
Diagonal FOV: 129°
Focal Length & FOV (4 mm)
Horizontal FOV: 86°
Vertical FOV: 47°
Diagonal FOV: 102°
Focal Length & FOV (6 mm)
Horizontal FOV: 55°
Vertical FOV: 29°
Diagonal FOV: 65°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.4
DORI
DORI (2.8 mm)
Detect: 44 m | Observe: 17 m | Recognize: 8 m | Identify: 4 m
DORI (4 mm)
Detect: 53 m | Observe: 21 m | Recognize: 10 m | Identify: 5 m
DORI (6 mm)
Detect: 86 m | Observe: 34 m | Recognize: 17 m | Identify: 8 m
Illuminator
Supplement Light Type
IR
Supplement Light Range
Up to 40 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
Video
Main Stream
50 Hz: up to 50 fps (1920 × 1080, 1280 × 720)
60 Hz: up to 60 fps (1920 × 1080, 1280 × 720)
*High frame rate is supported under certain settings.
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Fourth Stream
50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
*Fourth stream is supported under certain settings.
Video Compression
Main Stream: H.265 / H.264 / H.264+ / H.265+
Sub-Stream: H.265 / H.264 / MJPEG
Third Stream: H.265 / H.264
Fourth Stream: H.265 / H.264 / MJPEG
*Third stream and fourth stream are supported under certain settings.
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile / Main Profile / High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR / VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region of Interest (ROI)
5 fixed regions for main stream and sub-stream
Target Cropping
Yes
Audio
Audio Compression
G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
Audio Bit Rate
64 Kbps (G.711ulaw / G.711alaw)
16 Kbps (G.722.1)
16 Kbps (G.726)
32 to 192 Kbps (MP2L2)
8 to 320 Kbps (MP3)
16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
Environment Noise Filtering
Yes
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP,
NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour,
SSL/TLS, PPPoE, ARP, SNMP, WebSocket, WebSockets
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface
(Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
User / Host
Up to 32 users
3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption,
IP address filter, Security Audit Log, basic and digest
authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest
authentication for Open Network Video Interface
Network Storage
NAS (NFS, SMB/CIFS), auto network replenishment (ANR).
Together with high-end Hikvision memory card, memory card
encryption and health detection are supported.
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch
Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness,
gain, white balance adjustable by client software or web browser
Day / Night Switch
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)
120 dB
SNR
≥ 52 dB
Image Enhancement
BLC, HLC, 3D DNR
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Key Features
AcuSense
False alarm reduction through human and vehicle target
classification based on deep learning
Low-Light Performance
Excellent low-light performance with powered-by-DarkFighter technology
Backlight Compensation
120 dB True WDR
Compression
Efficient H.265+ compression technology
Advanced Streaming
Advanced streaming technology for smooth live view and
data self-correcting in poor network conditions
IR Illumination
IR range up to 40 m
Weather Protection
IP67 water and dust resistant
High-quality 2MP ColorVu Fixed Turret Network Camera designed for 24/7 colorful imaging and excellent low-light performance. Features an F1.0 large-aperture lens, 120 dB WDR, efficient H.265+ compression, human and vehicle detection, white light illumination, and IP67 water and dust resistance.
Technical Specifications
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.001 Lux @ (F1.0, AGC ON)
0 Lux with light
Shutter Time
1/3 s to 1/100,000 s
Day & Night
24/7 Color Imaging
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV (2.8 mm)
Horizontal FOV: 106°
Vertical FOV: 57°
Diagonal FOV: 127°
Focal Length & FOV (4 mm)
Horizontal FOV: 84°
Vertical FOV: 45°
Diagonal FOV: 99°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
DORI
DORI (2.8 mm)
Detect: 44 m | Observe: 17 m | Recognize: 8 m | Identify: 4 m
DORI (4 mm)
Detect: 56 m | Observe: 22 m | Recognize: 11 m | Identify: 5 m
Illuminator
Supplement Light Type
White Light
Supplement Light Range
Up to 30 m
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 1 fps (640 × 360)
60 Hz: 1 fps (640 × 360)
Video Compression
Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub-Stream: H.265 / H.264 / MJPEG
Third Stream: H.265 / H.264
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile, Main Profile, High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR, VBR
Region of Interest (ROI)
1 fixed region for main stream and sub-stream
Audio
Audio Type
Mono sound
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz / 16 kHz
Audio Compression
G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Audio Bit Rate
64 Kbps (G.711 ulaw) / 64 Kbps (G.711 alaw)
16 Kbps (G.722.1) / 16 Kbps (G.726)
32 to 160 Kbps (MP2L2)
16 to 64 Kbps (AAC-LC)
Network
Security
Password protection, complicated password, HTTPS encryption,
802.1X authentication (EAP-MD5), watermark, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication
for Open Network Video Interface, RTP/RTSP over HTTPS,
security audit log, TLS 1.2, TLS 1.3, host authentication
(MAC address)
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface
(Profile S, Profile T, Profile G), ISAPI, SDK
Protocols
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP,
IPv4, IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS, UPnP, 802.1X
User / Host
Up to 32 users
3 user levels: administrator, operator, and user
Client
iVMS-4200, Hik-Connect
Web Browser
Plug-in required live view: IE 10, IE 11
Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)
120 dB
SNR
≥ 52 dB
Day / Night Switch
Day, Night, Auto, Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness,
gain, white balance, adjustable by client software or web browser
Privacy Mask
4 programmable polygon privacy masks
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Key Features
ColorVu
24/7 colorful imaging with excellent low-light performance
Intelligent Detection
Human and Vehicle Detection
Compression
Efficient H.265+ compression technology to save bandwidth and storage
Backlight Compensation
120 dB WDR
Image Enhancement
3D DNR technology
Illumination
White Light, up to 30 m
Weather Protection
IP67 water and dust resistant
High-quality 2MP Smart Hybrid Light Fixed Dome Network Camera designed for reliable indoor and outdoor surveillance. Features Human and Vehicle Detection, 120 dB WDR, 3D DNR, Smart Hybrid Light technology, built-in microphone, PoE connectivity, and IP67 water and dust resistance with IK08 vandal protection.
Technical Specifications
Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
0 Lux with light
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355°
Lens
Lens Type
Fixed focal lens, 2.8 mm and 4 mm optional
Focal Length & FOV (2.8 mm)
Horizontal FOV: 111°
Vertical FOV: 59°
Diagonal FOV: 133°
Focal Length & FOV (4 mm)
Horizontal FOV: 91°
Vertical FOV: 46°
Diagonal FOV: 109°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.6
DORI
DORI (2.8 mm)
Detect: 43 m | Observe: 17 m | Recognize: 9 m | Identify: 5 m
DORI (4 mm)
Detect: 53 m | Observe: 21 m | Recognize: 11 m | Identify: 6 m
Illuminator
Supplement Light Type
IR, White Light
Supplement Light Range
Up to 30 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 1 fps (640 × 360)
60 Hz: 1 fps (640 × 360)
Video Compression
Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub-Stream: H.265 / H.264 / MJPEG
Third Stream: H.265 / H.264
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile, Main Profile, High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR, VBR
Region of Interest (ROI)
1 fixed region for main stream and sub-stream
Audio
Audio Type
Mono sound
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz / 16 kHz
Audio Compression
G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
Audio Bit Rate
64 Kbps (G.711ulaw / G.711alaw)
16 Kbps (G.722.1)
16 Kbps (G.726)
32 to 192 Kbps (MP2L2)
8 to 320 Kbps (MP3)
16 to 64 Kbps (AAC-LC)
Network
Security
Password protection, complicated password, HTTPS encryption,
802.1X authentication (EAP-MD5), watermark, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication
for Open Network Video Interface, RTP/RTSP over HTTPS,
security audit log, TLS 1.2, TLS 1.3, host authentication
(MAC address)
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface
(Profile S, Profile T, Profile G), ISAPI, SDK
Protocols
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP,
IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS, UPnP, 802.1X
User / Host
Up to 32 users
3 user levels: administrator, operator, and user
Client
iVMS-4200, Hik-Connect
Web Browser
Plug-in required live view: IE 10, IE 11
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Wide Dynamic Range (WDR)
120 dB
SNR
≥ 52 dB
Day / Night Switch
Day, Night, Auto, Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness,
gain, white balance, adjustable by client software or web browser
Privacy Mask
4 programmable polygon privacy masks
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Key Features
Detection
Human and Vehicle Detection
Smart Hybrid Light
IR and White Light with advanced long-range technology
Compression
Efficient H.265+ compression technology
Backlight Compensation
120 dB WDR
Audio
Built-in microphone for real-time audio security
PoE
Easy installation with Power over Ethernet (PoE) technology
Weather Protection
IP67 water and dust resistant
Vandal Resistance
IK08
High-quality 2MP Fixed Dome Network Camera designed for reliable indoor and outdoor surveillance. Features Human and Vehicle Detection, DWDR technology, efficient H.265+ compression, advanced EXIR 2.0 infrared technology, and IP67 water and dust resistance with IK08 vandal resistance.
Technical Specifications
Camera
Image Sensor
1/2.9" Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.01 Lux @ (F2.0, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 355°, Tilt: 0° to 75°
Lens
Lens Type
Fixed focal lens, 2.8 mm and 4 mm optional
Focal Length & FOV (2.8 mm)
Horizontal FOV: 104.9°
Vertical FOV: 58.3°
Diagonal FOV: 123.3°
Focal Length & FOV (4 mm)
Horizontal FOV: 81.3°
Vertical FOV: 43.7°
Diagonal FOV: 96.9°
Lens Mount
M12
Iris Type
Fixed
Aperture
F2.0
DORI
DORI (2.8 mm)
Detect: 42 m | Observe: 16 m | Recognize: 8 m | Identify: 4 m
DORI (4 mm)
Detect: 57 m | Observe: 22 m | Recognize: 11 m | Identify: 5 m
Illuminator
Supplement Light Type
IR
Supplement Light Range
Up to 40 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression
Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub-Stream: H.265 / H.264 / MJPEG
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile, Main Profile, High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR, VBR
Region of Interest (ROI)
1 fixed region for main stream and sub-stream
Network
Security
Password protection, complicated password, HTTPS encryption,
802.1X authentication (EAP-MD5), watermark, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication
for Open Network Video Interface, RTP/RTSP over HTTPS,
security audit log, TLS 1.2, TLS 1.3, host authentication
(MAC address)
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface
(Profile S, Profile T), ISAPI, SDK
Protocols
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP,
IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS,
UPnP, 802.1X
User / Host
Up to 32 users
3 user levels: administrator, operator, and user
Client
iVMS-4200, Hik-Connect
Web Browser
Plug-in required live view: IE 10, IE 11
Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)
Digital WDR
SNR
≥ 52 dB
Day / Night Switch
Day, Night, Auto, Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness,
gain, white balance, adjustable by client software or web browser
Privacy Mask
4 programmable polygon privacy masks
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Key Features
Detection
Human and Vehicle Detection
Infrared Technology
EXIR 2.0 advanced infrared technology with long IR range
Compression
Efficient H.265+ compression technology
Backlight Compensation
DWDR technology
Weather Protection
IP67 water and dust resistant
Vandal Resistance
IK08
