Advanced AI-powered 16-channel DVR featuring Motion Detection 2.0 with human and vehicle analysis, perimeter protection, facial detection and capture, and powerful IP expansion with 4K HDMI output—designed for large-scale intelligent surveillance systems.
Product Specifications
AI & Smart Features
Motion Detection
Motion Detection 2.0 (Deep Learning)
Human / Vehicle Analysis
Intelligent classification of humans and vehicles to significantly reduce false alarms caused by leaves, lights, and other environmental factors
Quick Search
Search by object or event type
Perimeter Protection
Line crossing detection and intrusion detection (up to 4 channels)
Facial Detection
Facial detection and capture, face picture detection and face picture search
Video & Audio Input
IP Video Input
2-ch (up to 18-ch)
Enhanced IP mode: 8-ch (up to 24-ch), up to 4 Mbps per channel
Up to 6 MP resolution
Supports H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
16-ch, BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported
HDTVI Input
3K@25/20 fps, 5 MP@20 fps, 4 MP@30/25 fps,
2K@20 fps, 1080p@30/25 fps, 720p@30/25 fps
AHD Input
5 MP@20 fps, 4 MP@30/25 fps,
1080p@30/25 fps, 720p@30/25 fps
HDCVI Input
3K@20/25 fps, 5 MP@20 fps, 4 MP@30/25 fps,
1080p@30/25 fps, 720p@30/25 fps
CVBS Input
PAL / NTSC
Video Output
HDMI Output
1-ch: 4K (3840 × 2160) @30Hz,
2K (2560 × 1440) @60Hz,
1920 × 1080 @60Hz,
1280 × 1024 @60Hz,
1280 × 720 @60Hz
VGA Output
1-ch: 1920 × 1080 @60Hz,
1280 × 1024 @60Hz, 1280 × 720 @60Hz
Audio
Audio Input
1-ch (up to 4-ch optional), RCA (2.0 Vp-p, 1 KΩ)
4-ch via coaxial cable
Audio Output
1-ch RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch RCA (using the first audio input)
Playback
Synchronous Playback
16-channel simultaneous playback
