Enterprise-grade 32-channel AI DVR featuring advanced facial recognition, Motion Detection 2.0, perimeter protection up to 16 channels, and powerful IP expansion up to 40 channels with 4K HDMI output—built for large-scale professional surveillance systems.
Product Specifications
AI & Smart Features
Facial Recognition Face picture comparison and face picture search
(4-ch face picture comparison alarm for HD analog cameras)
Face Picture Library Up to 16 face picture libraries
Face library data is protected—HDD damage will not cause data loss as the library is backed up by HDD and flash
Motion Detection Motion Detection 2.0 (Deep Learning)
Human / Vehicle Analysis Intelligent classification of humans and vehicles to significantly reduce false alarms caused by leaves, lights, and other environmental disturbances
Quick Search Search by object or event type
Perimeter Protection Human / vehicle analysis, up to 16 channels (advanced model)
Facial Detection Facial detection and capture
Face picture detection and face picture search
4-ch face picture capture
Video & Audio Input
IP Video Input 8-ch (up to 40-ch), each up to 6 MP resolution
Analog Video Input 32-ch, BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported
HDTVI Input 3K@25/20 fps, 5 MP@20 fps,
4 MP@25/30 fps, 1080p@25/30 fps, 720p@25/30 fps
AHD Input 5 MP@20 fps, 4 MP@25/30 fps,
1080p@25/30 fps, 720p@25/30 fps
HDCVI Input 3K@25 fps, 5 MP@20 fps, 4 MP@25/30 fps,
1080p@25/30 fps, 720p@25/30 fps
CVBS Input PAL / NTSC
Video Output
HDMI Output 1-ch: 4K (3840 × 2160) @30Hz,
2K (2560 × 1440) @60Hz,
1920 × 1080 @60Hz,
1280 × 1024 @60Hz,
1280 × 720 @60Hz
VGA Output 1-ch: 1920 × 1080 @60Hz,
1280 × 1024 @60Hz, 1280 × 720 @60Hz
CVBS Output 1-ch BNC (1.0 Vp-p, 75 Ω)
PAL: 704 × 576 / NTSC: 704 × 480
Video Output Mode HDMI / VGA simultaneous output
Audio
Audio Input 1-ch (up to 16-ch optional), RCA (2.0 Vp-p, 1 KΩ)
32-ch via coaxial cable
Audio Output 1-ch RCA (Linear, 1 KΩ)
Two-Way Audio 1-ch RCA (using the audio input)
Playback
Synchronous Playback 16-channel simultaneous playback
