DS-PS1-I-WE Wireless internal sounderv(Blue-red-green Indicators)
Product Specifications
Electrical characteristics
Operation humidity
10% to 90% (No condensing)
Operation temperature
-20°C to 60°C (-4 °F to 140 °F)
Battery life span
Up to 3 years (standby time)
Battery type
Battery (default power supply method) or 12 VDC
Power supply
Battery (default power supply method) or 12 VDC
General
Shell material
PC+ABS
IP rate
IP65
Wireless transmission
RF frequency
868 MHz
RF modulation
2GFSK
RF distance
1.6 KM(open area)
DS-PS1-I-WE Wireless internal sounder
Product Specifications
Electrical characteristics
Operation humidity
10% to 90% (No condensing)
Operation temperature
-10 °C to 55 °C (-4 °F to 131 °F)
Battery life span
Up to 3 years (standby time)
General
Shell material
PC+ABS
Color
Blue/Red LED flash
Wireless transmission
RF frequency
868 MHz
RF modulation
2GFSK
RF distance
1.6 KM(open area)
DS-PS1-I-WE Wireless internal sounder
Product Specifications
Electrical characteristics
Operation humidity
10% to 90% (No condensing)
Operation temperature
-10 °C to 55 °C (-4 °F to 131 °F)
Battery life span
Up to 3 years (standby time)
General
Shell material
PC+ABS
Color
Blue/Red LED flash
Wireless transmission
RF frequency
868 MHz
RF modulation
2GFSK
RF distance
1.6 KM(open area)
DS-PK1-E-WE Wireless LED keypad
Product Specifications
Hardware features
Power switch
Power on/off
Display
Indicator
5, area(blue), fault(orange), arm(blue), disarm(green), alarm(red), signal(red/green)
Electrical characteristics
Battery type
Three AA batteries
Operation humidity
10% to 90% (no condensing)
Wireless transmission
RF frequency
868 MHz
RF modulation
2GFSK
6 MP Dual Light MD 2.0 Varifocal Bullet Network Camera
Product Specifications
Camera
Image Sensor
1/2.4" Progressive Scan CMOS
Maximum Resolution
3200 × 1800
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 355°
Tilt: 0° to 70°
Rotate: 0° to 355°
Lens
Lens Type
Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV
2.8 to 12 mm, horizontal FOV 106° to 35.6°, vertical FOV 55.9° to 20°, diagonal FOV 127.4° to 40.8°
Lens Mount
Ø14
Iris Type
Fixed
Aperture
F1.6
4 MP Varifocal Dome Network Camera
Product Specifications
Camera
Image Sensor
1/3" Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 355°
Tilt: 0° to 70°
Rotate: 0° to 355°
Lens
Lens Type
Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV
2.8 to 12 mm— Horizontal: 102° to 31°, vertical FOV 54° to 17°, diagonal FOV 123° to 35°
Lens Mount
Ø14
Iris Type
Fixed
Aperture
F1.6
4 MP Dual Light MD 2.0 Varifocal Bullet Network Camera
Product Specifications
Camera
Image Sensor
1/3" Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 90°
Rotate: 0° to 360°
Lens
Lens Type
Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV
2.8 to 12 mm— Horizontal: FOV 96.7° to 29.7°, vertical FOV 51.7° to 16.7°, diagonal FOV 114.3° to 34°
Lens Mount
Ø14
Iris Type
Fixed
Aperture
F1.6
The CAT6 U/UTP Network Cable offers a cost-effective solution for indoor Ethernet installations. Utilizing Copper Clad Aluminum (CCA) conductors and unshielded twisted pair technology, this cable supports reliable Gigabit Ethernet speeds over distances up to 100 meters, making it perfectly suited for connecting routers, switches, PCs, and IP cameras.
Product Specifications
General
Cable Category
CAT6
Cable Type
U/UTP
Application
Network / Ethernet Cable
Usage Scenario
Indoor
Conductor Specifications
Conductor Material
CCA (Copper Clad Aluminum)
Conductor Diameter
0.55 mm
Pair Type
Twisted Pair
Shielding
Unshielded
Performance
Transmission Type
Data / LAN
Supported Network
Ethernet / Gigabit Ethernet
Max Distance
Up to 100 m
Compatibility
Compatible Devices
Routers, Switches, PCs, IP Cameras, NVRs
High-performance PoE network switch with durable metal housing, enhanced power capacity, flexible mounting options, and surge protection for reliable networking.
Product Specifications
General
Shell
Metal Material
Net Weight
0.56 kg (1.23 lb)
Gross Weight
0.64 kg (1.41 lb)
Dimensions (W × H × D)
175.0 × 44.0 × 124.0 mm (6.89 × 1.73 × 4.88 in)
Installation Mode
Desk-Mounted, Wall-Mounted
Environmental
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature
–40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity
5% to 95% (no condensation)
Relative Humidity
5% to 95% (no condensation)
Power
Power Supply
220 VAC, 50 Hz, 1.5 A
Max Power Consumption
60 W
Power Consumption (Idle)
3.4 W
Surge Protection
2 KV
Network Parameters
Ports
8 × 10/100 Mbps PoE ports, 2 × 10/100 Mbps RJ45 ports
MAC Address Table
2 K
Switching Capacity
2 Gbps
Packet Forwarding Rate
1.49 Mpps
Internal Cache
0.77 Mbits
Compact PoE network switch with metal shell, flexible mounting options, surge protection, and stable performance for small to medium network deployments.
Product Specifications
General
Shell Metal Material
Net Weight 0.54 kg (1.19 lb)
Gross Weight 0.58 kg (1.28 lb)
Dimensions (W × H × D) 175.0 × 44.0 × 124.0 mm (6.89 × 1.73 × 4.88 in)
Installation Mode Desk-Mounted, Wall-Mounted
Environmental
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature –40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity 5% to 95% (no condensation)
Relative Humidity 5% to 95% (no condensation)
Power
Power Supply 220 VAC, 50 Hz, 0.8 A
Max Power Consumption 35 W
Power Consumption (Idle) 2.0 W
Surge Protection 2 KV
Network Parameters
Ports 4 × 10/100 Mbps PoE ports, 2 × 10/100 Mbps RJ45 ports
MAC Address Table 2 K
Switching Capacity 1.2 Gbps
Packet Forwarding Rate 0.89 Mpps
Internal Cache 0.77 Mbits
Product Specifications
Camera
Image Sensor
1/3″ Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 75°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens (2.8 mm / 4 mm optional)
Focal Length & FOV
2.8 mm — H: 98°, V: 54°, D: 114°
4 mm — H: 78°, V: 42°, D: 93°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.6
Product Specifications
Camera
Image Sensor
1/3″ Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 355°
Tilt: 0° to 75°
Rotate: 0° to 355°
Lens
Lens Type
Fixed focal lens (2.8 mm / 4 mm optional)
Focal Length & FOV
2.8 mm — H: 98°, V: 54°, D: 114°
4 mm — H: 78°, V: 42°, D: 93°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.6
Product Specifications
Camera
Image Sensor
1/2.7″ Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.01 Lux @ (F2.2, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 75°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens (2.8 mm / 4 mm optional)
Focal Length & FOV
2.8 mm — H: 112°, V: 61°, D: 135°
4 mm — H: 89°, V: 48°, D: 105°
Depth of Field
2.8 mm: 0.9 m to ∞
4 mm: 1.1 m to ∞
Lens Mount
M12
Iris Type
Fixed
Aperture
F2.2
Product Specifications
Camera
Image Sensor
1/2.7″ Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.01 Lux @ (F2.2, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 90°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens (2.8 mm / 4 mm optional)
Focal Length & FOV
2.8 mm — H: 112°, V: 61°, D: 135°
4 mm — H: 89°, V: 48°, D: 105°
Depth of Field
2.8 mm: 0.9 m to ∞
4 mm: 1.1 m to ∞
Lens Mount
M12
Iris Type
Fixed
Aperture
F2.2
High-definition network camera with a progressive scan CMOS sensor,
adjustable mounting angles, and flexible lens options, designed for
reliable day and night surveillance.
Product Specifications
Camera
Image Sensor
1/3" Progressive Scan CMOS
Max. Resolution
1920 × 1080
Minimum Illumination
Color: 0.01 Lux @ (F2.2, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 75°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8 mm and 4 mm optional
Focal Length & FOV
2.8 mm: Horizontal 97°, Vertical 54°, Diagonal 113°
4 mm: Horizontal 76°, Vertical 42°, Diagonal 90°
Lens Mount
M12
Iris Type
Fixed
Aperture
F2.2
Depth of Field
2.8 mm: 0.8 m to ∞
4 mm: 1 m to ∞
The Hikvision DS-7632NXI-K2/Vpro is a 32-channel 1U AcuSeek K VPro Network Video Recorder featuring advanced AI-powered facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, and AcuSeek technology.
Product Specifications
General Information
Model DS-7632NXI-K2/Vpro
Product Type 32-ch 1U AcuSeek K VPro NVR
Intelligent Analytics
AI by NVR Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, AcuSeek
AI by NVR and Camera Facial recognition, perimeter protection, Motion Detection 2.0, ANPR, VCA
AcuSearch
By Camera All channels
AcuSeek
Performance If the cameras support Hikvision AcuSense Technology and have enabled the AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling up to 50,000 targets per day.
Search Language English
Perimeter Protection
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarms.Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
By Camera All channels
Target Recognition
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total.Maximum picture size: 1 MB eachTotal capacity: Up to 800 MB
Face Picture Comparison 8-ch
Facial Detection and Analytics Performance Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
Motion Detection 2.0
By NVR All channels, up to 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, supports up to 8 MP.
By Camera All channels
Video & Audio
IP Video Input 32-ch
Incoming Bandwidth 256 Mbps
Outgoing Bandwidth 100 Mbps
IP Speaker Input 4-ch
HDMI Output 4K (3840 × 2160) @ 30 Hz2K (2560 × 1440) @ 60 Hz1080P (1920 × 1080) @ 60 HzUXGA (1600 × 1200) @ 60 HzSXGA (1280 × 1024) @ 60 Hz720P (1280 × 720) @ 60 Hz
Decoding
Decoding Format H.265 / H.265+ / H.264 / H.264+
Network
Network Interface 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection 128
Auxiliary Interface
SATA 2 SATA interfaces
General
Power Supply 12 VDC, 3.33 A
Certification
Obtained Certifications CE, CB, REACH, WEEE, UKCA, RCM, IC
CE Standards EN 55032: 2015EN 61000-3-2EN 61000-3-3EN 50130-4EN 55035: 2017
Warranty
Warranty Period 2 Years
The Hikvision DS-7616NXI-K2/Vpro is a 16-channel 1U AcuSeek K VPro Network Video Recorder featuring advanced AI-powered facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, and AcuSeek technology.
Product Specifications
General Information
Model DS-7616NXI-K2/Vpro
Product Type 16-ch 1U AcuSeek K VPro NVR
Intelligent Analytics
AI by NVR Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, AcuSeek
AI by NVR and Camera Facial recognition, perimeter protection, Motion Detection 2.0, ANPR, VCA
AcuSearch
By Camera All channels
AcuSeek
Performance If the cameras support Hikvision AcuSense Technology and have enabled the AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling up to 50,000 targets per day.
Search Language English
Perimeter Protection
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarms.Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
By Camera All channels
Target Recognition
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total.Maximum picture size: 1 MB eachTotal capacity: Up to 800 MB
Face Picture Comparison 8-ch
Facial Detection and Analytics Performance Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
Motion Detection 2.0
By NVR All channels, up to 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, supports up to 8 MP.
By Camera All channels
Video & Audio
IP Video Input 16-ch
Incoming Bandwidth 160 Mbps
Outgoing Bandwidth 160 Mbps
IP Speaker Input 4-ch
HDMI Output 4K (3840 × 2160) @ 30 Hz2K (2560 × 1440) @ 60 Hz1080P (1920 × 1080) @ 60 HzUXGA (1600 × 1200) @ 60 HzSXGA (1280 × 1024) @ 60 Hz720P (1280 × 720) @ 60 Hz
Decoding
Decoding Format H.265 / H.265+ / H.264 / H.264+
Network
Network Interface 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection 128
Auxiliary Interface
SATA 2 SATA interfaces
General
Power Supply 12 VDC, 3.33 A
Certification
Obtained Certifications CE, CB, REACH, WEEE, UKCA, RCM, IC
CE Standards EN 55032: 2015EN 61000-3-2EN 61000-3-3EN 50130-4EN 55035: 2017
Warranty
Warranty Period 2 Years
The Hikvision DS-7608NXI-K2/Vpro is an 8-channel 1U AcuSeek K VPro Network Video Recorder featuring advanced AI-powered facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, and AcuSeek technology.
Product Specifications
General Information
Model DS-7608NXI-K2/Vpro
Product Type 8-ch 1U AcuSeek K VPro NVR
Intelligent Analytics
AI by NVR Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, AcuSeek
AI by NVR and Camera Facial recognition, perimeter protection, Motion Detection 2.0, ANPR, VCA
AcuSearch
By Camera All channels
AcuSeek
Performance If the cameras support Hikvision AcuSense Technology and have enabled the AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling up to 50,000 targets per day.
Search Language English
Perimeter Protection
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarms.Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
By Camera All channels
Target Recognition
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total.Maximum picture size: 1 MB eachTotal capacity: Up to 800 MB
Face Picture Comparison 8-ch
Facial Detection and Analytics Performance Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
Motion Detection 2.0
By NVR All channels, up to 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, supports up to 8 MP.
By Camera All channels
Video & Audio
IP Video Input 8-ch
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 160 Mbps
IP Speaker Input 4-ch
HDMI Output 4K (3840 × 2160) @ 30 Hz2K (2560 × 1440) @ 60 Hz1080P (1920 × 1080) @ 60 HzUXGA (1600 × 1200) @ 60 HzSXGA (1280 × 1024) @ 60 Hz720P (1280 × 720) @ 60 Hz
Decoding
Decoding Format H.265 / H.265+ / H.264 / H.264+
Network
Network Interface 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection 128
Auxiliary Interface
SATA 2 SATA interfaces
General
Power Supply 12 VDC, 3.33 A
Certification
Obtained Certifications CE, CB, REACH, WEEE, UKCA, RCM, IC
CE Standards EN 55032: 2015EN 61000-3-2EN 61000-3-3EN 50130-4EN 55035: 2017
Warranty
Warranty Period 2 Years
The Hikvision DS-7616NXI-K1/Vpro is a 16-channel 1U AcuSeek K VPro Network Video Recorder featuring advanced AI-powered facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, and AcuSeek technology.
Product Specifications
General Information
Model DS-7616NXI-K1/Vpro
Product Type 16-ch 1U AcuSeek K VPro NVR
Intelligent Analytics
AI by NVR Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, AcuSeek
AI by NVR and Camera Facial recognition, perimeter protection, Motion Detection 2.0, ANPR, VCA
AcuSearch
By Camera All channels
AcuSeek
Performance If the cameras support Hikvision AcuSense Technology and have enabled the AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling up to 50,000 targets per day.
Search Language English
Perimeter Protection
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarms.Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
By Camera All channels
Target Recognition
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total.Maximum picture size: 1 MB eachTotal capacity: Up to 800 MB
Face Picture Comparison 8-ch
Facial Detection and Analytics Performance Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
Motion Detection 2.0
By NVR All channels, up to 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, supports up to 8 MP.
By Camera All channels
Video & Audio
IP Video Input 16-ch
Incoming Bandwidth 160 Mbps
Outgoing Bandwidth 80 Mbps
IP Speaker Input 4-ch
HDMI Output 4K (3840 × 2160) @ 30 Hz2K (2560 × 1440) @ 60 Hz1080P (1920 × 1080) @ 60 HzUXGA (1600 × 1200) @ 60 HzSXGA (1280 × 1024) @ 60 Hz720P (1280 × 720) @ 60 Hz
Decoding
Decoding Format H.265 / H.265+ / H.264 / H.264+
Network
Network Interface 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Auxiliary Interface
SATA 1 SATA interface
General
Power Supply 12 VDC, 1.5 A
Certification
Obtained Certifications CE, CB, REACH, WEEE, UKCA, RCM, IC
CE Standards EN 55032: 2015EN 61000-3-2EN 61000-3-3EN 50130-4EN 55035: 2017
Warranty
Warranty Period 2 Years
The Hikvision DS-7608NXI-K1/Vpro is an 8-channel 1U AcuSeek K VPro Network Video Recorder featuring advanced AI-powered facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, and AcuSeek technology.
Product Specifications
General Information
Model DS-7608NXI-K1/Vpro
Product Type 8-ch 1U AcuSeek K VPro NVR
Intelligent Analytics
AI by NVR Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, AcuSeek
AI by NVR and Camera Facial recognition, perimeter protection, Motion Detection 2.0, ANPR, VCA
AcuSearch
By Camera All channels
AcuSeek
Performance If the cameras support Hikvision AcuSense Technology and have enabled the AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling up to 50,000 targets per day.
Search Language English
Perimeter Protection
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarms.Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
By Camera All channels
Motion Detection 2.0
By NVR All channels, up to 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, supports up to 8 MP.
By Camera All channels
Video & Audio
IP Video Input 8-ch
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 80 Mbps
IP Speaker Input 4-ch
HDMI Output 4K (3840 × 2160) @ 30 Hz2K (2560 × 1440) @ 60 Hz1080P (1920 × 1080) @ 60 HzUXGA (1600 × 1200) @ 60 HzSXGA (1280 × 1024) @ 60 Hz720P (1280 × 720) @ 60 Hz
Decoding
Decoding Format H.265 / H.265+ / H.264 / H.264+
Recording Resolution 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Synchronous Playback 8-ch
Network
Network Interface 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection 128
Auxiliary Interface
SATA 1 SATA interface
HDD Capacity Up to 16 TB capacity for each HDD
General
Power Supply 12 VDC, 1.5 A
Certification
Obtained Certifications CE, CB, REACH, WEEE, UKCA, RCM, IC
CE Standards EN 55032: 2015EN 61000-3-2EN 61000-3-3EN 50130-4EN 55035: 2017
Warranty
Warranty Period 2 Years
The Hikvision DS-7604NXI-K1/Vpro is a 4-channel 1U AcuSeek K VPro Network Video Recorder featuring advanced AI-powered facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, and AcuSeek technology.
Product Specifications
General Information
Model DS-7604NXI-K1/Vpro
Product Type 4-ch 1U AcuSeek K VPro NVR
Intelligent Analytics
AI by NVR Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch, AcuSeek
AI by NVR and Camera Facial recognition, perimeter protection, Motion Detection 2.0, ANPR, VCA
AcuSearch
By Camera All channels
AcuSeek
Performance If the cameras support Hikvision AcuSense Technology and have enabled the AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling up to 50,000 targets per day.
Search Language English
Perimeter Protection
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarms.Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
By Camera All channels
Target Recognition
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total.Maximum picture size: 1 MB eachTotal capacity: Up to 800 MB
Face Picture Comparison 4-ch
Facial Detection and Analytics Performance Up to 4 MP: 2-ch5 MP to 8 MP: 1-ch
Motion Detection 2.0
By NVR All channels, up to 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, supports up to 8 MP.
By Camera All channels
Video & Audio
IP Video Input 4-ch
Incoming Bandwidth 40 Mbps
Outgoing Bandwidth 80 Mbps
IP Speaker Input 4-ch
HDMI Output 4K (3840 × 2160) @ 30 Hz2K (2560 × 1440) @ 60 Hz1080P (1920 × 1080) @ 60 HzUXGA (1600 × 1200) @ 60 HzSXGA (1280 × 1024) @ 60 Hz720P (1280 × 720) @ 60 Hz
Decoding
Decoding Format H.265 / H.265+ / H.264 / H.264+
Recording Resolution 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Synchronous Playback 4-ch
Network
Network Interface 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection 128
Auxiliary Interface
SATA 1 SATA interface
HDD Capacity Up to 16 TB capacity for each HDD
General
Power Supply 12 VDC, 1.5 A
Certification
Obtained Certifications CE, CB, REACH, WEEE, UKCA, RCM, IC
CE Standards EN 55032: 2015EN 61000-3-2EN 61000-3-3EN 50130-4EN 55035: 2017
Warranty
Warranty Period 2 Years
High-resolution 2K security camera with a 1/2.7″ Progressive Scan CMOS sensor, fixed 4 mm lens option, and dependable IR night vision for clear monitoring in low-light environments.
Product Specifications
Camera
Image Sensor
1/2.7″ Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Lens
Lens Type
Fixed focal lens (4 mm optional)
Focal Length & FOV
4 mm — Horizontal: 70°, Vertical: 35°, Diagonal: 85°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.6
Full HD security camera featuring a 1/3″ Progressive Scan CMOS sensor, wide-angle 2.8 mm fixed focal lens, and reliable IR night vision for continuous day and night monitoring.
Product Specifications
Camera
Image Sensor
1/3″ Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.04 Lux @ (F2.0, AGC ON)
B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Lens
Lens Type
Fixed focal lens (2.8 mm optional)
Focal Length & FOV
2.8 mm — Horizontal: 101°, Vertical: 56°, Diagonal: 118°
Lens Mount
M12
Iris Type
Fixed
Aperture
F2.0
High-definition 2K security camera with a 1/3″ Progressive Scan CMOS sensor, fixed 4 mm lens, and dual illuminator system featuring IR and white light for reliable night-time monitoring.
Product Specifications
Camera
Image Sensor
1/3″ Progressive Scan CMOS
Maximum Resolution
2560 × 1440
Minimum Illumination
Color: 0.01 Lux @ (F2.0, AGC ON)
B/W: 0.005 Lux @ (F2.0, AGC ON)
0 Lux with light
Lens
Focal Length
4 mm
Field of View (FOV)
Horizontal: 70°
Vertical: 35°
Diagonal: 85°
Aperture
F1.6
Illuminator
Supplement Light Type
IR & White Light
Supplement Light Range
White Light: up to 30 m
IR: up to 30 m
IR Wavelength
850 nm
Full HD security camera with a 1/2.9″ Progressive Scan CMOS sensor, wide-angle 2.8 mm lens, and dual illuminator support with IR and white light for clear day and night surveillance.
Product Specifications
Camera
Image Sensor
1/2.9″ Progressive Scan CMOS
Maximum Resolution
1920 × 1080
Minimum Illumination
Color: 0.01 Lux @ (F2.0, AGC ON)
B/W: 0.005 Lux @ (F2.0, AGC ON)
0 Lux with light
Lens
Focal Length
2.8 mm
Field of View (FOV)
Horizontal: 105°
Vertical: 58°
Diagonal: 123°
Aperture
F2.0
Illuminator
Supplement Light Type
IR & White Light
Supplement Light Range
White Light: up to 30 m
IR: up to 30 m
IR Wavelength
850 nm
High-resolution security camera with a 1/2.4″ Progressive Scan CMOS sensor, sharp 3200 × 1800 output, ultra-low light performance with F1.0 aperture, and a 4 mm fixed focal lens for precise surveillance coverage.
Product Specifications
Camera
Image Sensor
1/2.4″ Progressive Scan CMOS
Maximum Resolution
3200 × 1800
Minimum Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON)
0 Lux with light
Shutter Time
1 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 180°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens (4 mm optional)
Focal Length & FOV
4 mm — Horizontal: 89°, Vertical: 49°, Diagonal: 105°
Depth of Field
4 mm: 2.4 m to ∞
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
High-performance security camera featuring a 1/2.4″ Progressive Scan CMOS sensor, sharp 3200 × 1800 resolution, excellent low-light sensitivity with F1.0 aperture, and a 2.8 mm fixed focal lens option for wide-angle surveillance coverage.
Product Specifications
Camera
Image Sensor
1/2.4″ Progressive Scan CMOS
Maximum Resolution
3200 × 1800
Minimum Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON)
0 Lux with light
Shutter Time
1 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 75°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens (2.8 mm optional)
Focal Length & FOV
2.8 mm — Horizontal: 109°, Vertical: 60°, Diagonal: 130°
Depth of Field
2.8 mm: 1.9 m to ∞
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
High-performance security camera featuring a 1/2.4″ Progressive Scan CMOS sensor, ultra-clear 3200 × 1800 resolution, excellent low-light sensitivity with F1.0 aperture, and a 4 mm fixed focal lens option for accurate surveillance coverage.
Product Specifications
Camera
Image Sensor
1/2.4″ Progressive Scan CMOS
Maximum Resolution
3200 × 1800
Minimum Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON)
0 Lux with light
Shutter Time
1 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°
Tilt: 0° to 90°
Rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens (4 mm optional)
Focal Length & FOV
4 mm — Horizontal: 89°, Vertical: 49°, Diagonal: 105°
Depth of Field
4 mm: 2.4 m to ∞
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
The Hikvision DS-2CD1T67G3-LIU is a 6MP ColorVu Smart Hybrid Light Fixed Bullet Network Camera engineered for 24/7 vivid color imaging in low-light environments. Featuring an advanced F1.0 large aperture lens, ColorVu technology for full-color performance around the clock, Motion Detection 3.0 with deep-learning-based human and vehicle classification, smart dual-light illumination up to 50 meters, a built-in microphone for real-time audio, and IP67 weather resistance, it delivers crisp, intelligent ultra-high-definition long-range 6MP security monitoring day and night.
Product Specifications
Camera & Imaging
Image Sensor 1/2.4" Progressive Scan CMOS
Max. Resolution 3200 × 1800 (6 MP)
Frame Rate 50 Hz: 20 fps (3200 × 1800), 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz: 20 fps (3200 × 1800), 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Min. Illumination Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Wide Dynamic Range (WDR) 120 dB WDR
Lens & Illumination
Lens Type 2.8 mm or 4 mm fixed focal lens
Field of View 109° (2.8 mm) / 89° (4 mm)
Smart Hybrid Light Range Up to 50 m white light / IR range
Smart & Video Analytics
Human & Vehicle Classification Motion detection 3.0 supporting human and vehicle target classification
Audio & Network
Audio Built-in microphone for real-time audio security
Network Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Video Compression H.265+ / H.265 / H.264+ / H.264
General & Environment
Operating Power 12 VDC ± 25%, PoE (802.3af)
Protection Level IP67
Operating Conditions -30 °C to 60 °C, humidity: 95% or less
Material & Dimensions Enclosure: Metal & Plastic, 253 mm × 197 mm × 144.6 mm
Weight Approx. 450 g
The Hikvision DS-2CD1367G3-LIU is a 6MP ColorVu Smart Hybrid Light Fixed Turret Network Camera engineered for 24/7 vivid color imaging in low-light environments. Featuring an advanced F1.0 large aperture lens, ColorVu technology for full-color performance around the clock, Motion Detection 3.0 with deep-learning-based human and vehicle classification, smart dual-light illumination up to 20 meters, a built-in microphone for real-time audio, and IP67 weather resistance, it delivers crisp, intelligent ultra-high-definition 6MP security monitoring day and night.
Product Specifications
Camera & Imaging
Image Sensor 1/2.4" Progressive Scan CMOS
Max. Resolution 3200 × 1800 (6 MP)
Frame Rate 50 Hz: 20 fps (3200 × 1800), 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz: 20 fps (3200 × 1800), 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Min. Illumination Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Wide Dynamic Range (WDR) 120 dB WDR
Lens & Illumination
Lens Type 2.8 mm or 4 mm fixed focal lens
Field of View 109° (2.8 mm) / 89° (4 mm)
Smart Hybrid Light Range Up to 30 m white light / IR range
Smart & Video Analytics
Human & Vehicle Classification Motion detection 3.0 supporting human and vehicle target classification
Audio & Network
Audio Built-in microphone for real-time audio security
Network Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Video Compression H.265+ / H.265 / H.264+ / H.264
General & Environment
Operating Power 12 VDC ± 25%, PoE (802.3af)
Protection Level IP67
Operating Conditions -30 °C to 60 °C, humidity: 95% or less
Material & Dimensions Enclosure: Metal & plastic, Ø 110 mm × 102.7 mm
Weight Approx. 390 g
High-performance security camera featuring a 1/2.4″ Progressive Scan CMOS sensor, sharp 3200 × 1800 resolution, strong low-light capability with F1.0 aperture, and a 4 mm fixed focal lens option for accurate surveillance coverage.
Product Specifications
Camera
Image Sensor
1/2.4″ Progressive Scan CMOS
Maximum Resolution
3200 × 1800
Minimum Illumination
Color: 0.001 Lux @ (F1.0, AGC ON)
0 Lux with light
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 355°
Tilt: 0° to 180°
Rotate: 0° to 355°
Lens
Lens Type
Fixed focal lens (4 mm optional)
Focal Length & FOV
4 mm — Horizontal: 94°, Vertical: 50°, Diagonal: 110°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
