WD85PURZ-8TB WD Purple Surveillance Hard Drive - 8TB Product Specifications General Specifications Capacity 8TB Form Factor 3.5-Inch Connector SATA Interface SATA Transfer Rate up to 215MB/s Disk Speed (RPM) 5640 RPM Recording Technology CMR Cache Size 256MB Warranty 3-Year Limited Warranty Dimensions (L x W x H) 5.79" x 4" x 1.03" Weight 720gms Model Number WD85PURZ Operating Temperature 0°C to 65°C Non-Operating Temperature -40°C to 70°C Product Features Feature 1 Engineered for mainstream surveillance systems Feature 2 WD AllFrame technology delivers optimizations for write-intensive, low bit-rate, high stream-count workloads typical to mainstream surveillance applications Feature 3 Supports up to 180TB/yr workload rate and up to 16 bays Compatibility HD Cameras Support Up to 64 HD cameras Drive Bays Up to 16 drive bays Firmware Technology AllFrame firmware technology

Read more less

DS120HKAI-VX1 12TB SATA Hard DriveHigh-performance enterprise-grade hard drive designed for AI and surveillance applications with 24/7 reliability and exceptional workload capacity.Specifications Category Specification Value General Interface SATA Formatted Capacity 12 TB Performance Interface Speed 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s Rotation Speed 7200 RPM Buffer Size 512 MB Max Data Transfer Speed 260 MB/s (Sustained, Typ.) Power Supply Voltage 12V ± 10% / 5V ± 5% Operating (Typ.) 8.08 W Active Idle (Typ.) 4.16 W Standby (Typ.) 0.43 W Acoustics Low Power Idle (Typ.) 31 dB Environmental Operating Temperature (Ambient) 5°C to 55°C Operating Temperature (Enclosure) 5°C to 60°C Non-Operating Temperature -40°C to 70°C Operating Humidity 5% to 90% RH Operating Altitude -305m to 3048m Non-Operating Altitude -305m to 12,192m Shock & Vibration Operating Shock 490 m/s² (50G, 2ms) Non-Operating Shock 1960 m/s² (200G, 2ms) Operating Vibration 7.35 m/s² (0.75G, 5-300Hz) / 2.45 m/s² (0.25G, 300-500Hz) Reliability MTTF / AFR 2,500,000 hours / 0.35% Non-recoverable Error Rate 10 per 10¹⁶ bits read Load/Unload Cycles 600,000 times Availability 24/7 Operation Rated Annual Workload 550 TB/year Physical Width 101.85 mm Height (Max) 26.1 mm Length (Max) 147.0 mm Weight (Max) 720 g Key Features Enterprise-grade reliability with 2.5 million hours MTTF Ultra-low 0.35% annualized failure rate High-speed 7200 RPM for superior performance Large 512MB cache buffer for enhanced data handling Exceptional workload capacity up to 550TB/year 24/7 operation capability for continuous use AI and surveillance optimized Wide operating temperature range (5°C to 55°C)

Read more less

High-Performance Surveillance Hard DrivesProfessional-grade SATA hard drives designed for 24/7 surveillance systems, supporting up to 32 high-definition camera streams with reliable performance and durability.Technical Specifications Category Specification DS40HKVS-VX1 DS20HKVS-VX1 Basic Interface SATA Formatted Capacity 4 TB 2 TB Performance Interface Speed 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s Rotation Speed 5400 rpm Buffer Size 128 MB Max Data Transfer Speed (Sustained) 176.4 MB/s Data Block Logical Data Block Length HOST: 512 B, DISK: 4096 B Supply Voltage Allowable Voltage 12 V ± 10% / 5 V ± 5% Power Consumption Operating (Typ.) 4.11 W 4.01 W Active Idle (Typ.) 2.36 W 2.08 W Standby (Typ.) 0.20 W 0.31 W Acoustics Low Power Idle (Typ.) 22 dB 21 dB Environmental Ambient Temp (Operating) 0°C to 60°C Ambient Temp (Non-Operating) -40°C to 70°C Relative Humidity (Operating) 5% to 90% R.H. Altitude (Operating) -305m to 3048m Shock (Operating) 686 m/s² (70G, 2ms) Reliability MTTF / AFR 1,000,000 hours / 0.88% Non-recoverable Error Rate 1 error per 10¹⁴ bits read Availability 24 hours/day, 7 days/week Rated Annual Workload 180 TB/year Mechanical Width 101.6 mm ± 0.25 mm Height (Max) 26.1 mm Length (Max) 147.0 mm Weight (Max) 650 g 440 g Key Features Supports up to 32 cameras high-definition streams 128 MB Cache buffer helps smooth video recording and guards against frame drops Designed for 24x7 operation Annual workload rating of 180 TB/year MTTF of 1M hours Industry-standard 3.5-inch form-factor and SATA interface Advanced Format 512e Sector Technology

Read more less

High-Performance 6TB Surveillance Hard DriveProfessional-grade SATA hard drive designed for 24/7 surveillance systems, supporting up to 32 high-definition camera streams with reliable performance and durability. Features 256MB cache buffer for smooth video recording.Technical Specifications Category Specification Value Basic Interface SATA Formatted Capacity 6 TB Performance Interface Speed 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s Rotation Speed 5400 rpm Buffer Size 256 MB Maximum Data Transfer Speed (Sustained) 176.4 MB/s Logical Data Block Length HOST: 512 B, DISK: 4096 B Supply Voltage Allowable Voltage 12 V ± 10% / 5 V ± 5% Power Consumption Operating (Typ.) 4.84 W Active Idle (Typ.) 2.81 W Standby (Typ.) 0.36 W Acoustics Low Power Idle (Typ.) 24 dB Environmental Limits Item Specification Ambient Temperature (Operating) 0°C to 60°C (No condensation) Ambient Temperature (Non-Operating) -40°C to 70°C (No condensation) Enclosure Surface Temperature (Operating) 0°C to 70°C (No condensation) Relative Humidity (Operating) 5% to 90% R.H. (No condensation) Relative Humidity (Non-Operating) 5% to 95% R.H. (No condensation) Altitude (Operating) -305m to 3048m Altitude (Non-Operating) -305m to 12192m Shock (Operating) 686 m/s² (70G, 2ms duration) Shock (Non-Operating) 2940 m/s² (300G, 2ms duration) Vibration (Operating) 4.90 m/s² (0.50G, 5-350Hz) / 2.45 m/s² (0.25G, 350-500Hz) Vibration (Non-Operating) 29.4 m/s² (3.0G, 5-500Hz) Reliability Item Specification MTTF / AFR 1,000,000 hours / 0.88% Non-recoverable Error Rate 1 error per 10¹⁴ bits read Load / Unload 600,000 times Availability 24 hours/day, 7 days/week Rated Annual Workload 180 TB/year (R/W) Mechanical Specifications Item Specification Width 101.6 mm ± 0.25 mm Height (Max) 26.1 mm Length (Max) 147.0 mm Weight (Max) 680 g Key Features 6TB storage capacity for extended surveillance recording 256MB cache buffer for superior performance and smooth video recording Supports up to 32 high-definition camera streams Designed for 24x7 continuous operation Annual workload rating of 180TB/year MTTF of 1 million hours for exceptional reliability Industry-standard 3.5-inch form-factor with SATA interface Advanced Format 512e Sector Technology Optimized for surveillance and security systems

Read more less

High-Performance Surveillance Hard Drives Professional-grade SATA hard drives designed for 24/7 surveillance systems, supporting up to 32 high-definition camera streams with reliable performance and durability. Technical Specifications Category Specification DS40HKVS-VX1 DS20HKVS-VX1 Basic Interface SATA Formatted Capacity 4 TB 2 TB Performance Interface Speed 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s Rotation Speed 5400 rpm Buffer Size 128 MB Max Data Transfer Speed (Sustained) 176.4 MB/s Data Block Logical Data Block Length HOST: 512 B, DISK: 4096 B Supply Voltage Allowable Voltage 12 V ± 10% / 5 V ± 5% Power Consumption Operating (Typ.) 4.11 W 4.01 W Active Idle (Typ.) 2.36 W 2.08 W Standby (Typ.) 0.20 W 0.31 W Acoustics Low Power Idle (Typ.) 22 dB 21 dB Environmental Ambient Temp (Operating) 0°C to 60°C Ambient Temp (Non-Operating) -40°C to 70°C Relative Humidity (Operating) 5% to 90% R.H. Altitude (Operating) -305m to 3048m Shock (Operating) 686 m/s² (70G, 2ms) Reliability MTTF / AFR 1,000,000 hours / 0.88% Non-recoverable Error Rate 1 error per 10¹⁴ bits read Availability 24 hours/day, 7 days/week Rated Annual Workload 180 TB/year Mechanical Width 101.6 mm ± 0.25 mm Height (Max) 26.1 mm Length (Max) 147.0 mm Weight (Max) 650 g 440 g Key Features Supports up to 32 cameras high-definition streams 128 MB Cache buffer helps smooth video recording and guards against frame drops Designed for 24x7 operation Annual workload rating of 180 TB/year MTTF of 1M hours Industry-standard 3.5-inch form-factor and SATA interface Advanced Format 512e Sector Technology

Read more less
