High-performance online UPS with three-phase input and single-phase output, designed for critical power applications, offering high efficiency, zero transfer time, advanced battery management, and comprehensive protection features.
Product Specifications
Input
Input Wiring Three-phase five-wire (3Φ + N + PE)
Rated Voltage 380 / 400 / 415 Vac
Voltage Range 190 ~ 305 Vac (Linear derating 50%–100% load)
305 ~ 499 Vac (No derating)
Rated Frequency 50 / 60 Hz (Auto-sensing)
Frequency Range 40 ~ 70 Hz
Input Power Factor ≥ 0.99
Bypass Voltage Range -40% ~ +15% (Settable)
Input THDi ≤ 5%
Output
Output Wiring Single-phase three-wire (1Φ + N + PE)
Rated Output Voltage 208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage Regulation ± 1%
Output Frequency Synchronized to bypass in mains mode
50 / 60 Hz ± 0.1% in battery mode
Waveform Pure Sinusoidal
Output Power Factor 1.0
Output THDv ≤ 1% (Linear load)
≤ 3% (Non-linear load)
Crest Factor 3 : 1
Overload Capacity 105%–110%: 10 min
110%–125%: 1 min
126%–150%: 30 s
Battery
DC Voltage 192 Vdc (192 ~ 240 Vdc settable)
Number of Batteries 16 pcs (16 ~ 20 settable)
Inbuilt Battery (Standard Model) 12 V / 9 Ah × 16
Charging Current Standard model: 1 A
Long-time model: 5 A (Default), 1 ~ 5 A settable
Optional: 10 A
Recharge Time Standard model: 90% capacity in 8 hours
Long-time model: Depends on battery capacity
System
Efficiency ≥ 94% at 100% load
Max. 95% at 60% load
≥ 98% in ECO mode
Transfer Time 0 ms
Protections Short-circuit, output overload, overtemperature, battery low voltage, overvoltage / undervoltage, fan failure
Max. Parallel Units Up to 4 units
Communications RS232 (Standard)
Optional: USB, RS485, Dry Contacts, SNMP, Battery Temperature Compensation
Display LCD + LED
Environmental & Physical
Operating Temperature 0 ℃ ~ 40 ℃
Storage Temperature -25 ℃ ~ 55 ℃ (Without battery)
Relative Humidity 0 ~ 95% (Non-condensing)
Altitude ≤ 1000 m (Derating 1% per additional 100 m)
IP Rating IP20
Noise Level (1 m) ≤ 58 dB
Dimensions & Weight
Dimensions (W × D × H) 191 × 495 × 711 mm (S)
191 × 495 × 350 mm (H)
191 × 495 × 515 mm (H)
Packaged Dimensions 310 × 685 × 941 mm (S)
318 × 617 × 475 mm (H)
285 × 593 × 618 mm (H)
Net Weight 64 kg (S), 18.5 kg (H), 26.5 kg (H)
Gross Weight 72 kg (S), 20 kg (H), 28 kg (H)
