Intelligent AI DVR featuring Motion Detection 2.0 with human and vehicle analysis, facial detection and capture, and flexible IP expansion—ideal for smart small-scale surveillance installations.
Product Specifications
AI & Smart Features
Motion Detection
Motion Detection 2.0 (Deep Learning)
Human / Vehicle Analysis
Intelligent classification of human and vehicle targets to significantly reduce false alarms caused by leaves, lights, and other disturbances
Quick Search
Search by object or event type
Facial Detection
Facial detection and capture, face picture detection and face picture search
Video & Audio Input
IP Video Input
1-ch (up to 5-ch)
Enhanced IP mode: 2-ch (up to 6-ch), up to 4 Mbps per channel
Up to 6 MP resolution
Supports H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
4-ch, BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported
HDTVI Input
3K@25/20 fps, 5 MP@20 fps, 4 MP@30/25 fps,
2K@20 fps, 1080p@30/25 fps, 720p@30/25 fps
AHD Input
5 MP@20 fps, 4 MP@30/25 fps,
1080p@30/25 fps, 720p@30/25 fps
HDCVI Input
3K@25/20 fps, 5 MP@20 fps, 4 MP@30/25 fps,
1080p@30/25 fps, 720p@30/25 fps
CVBS Input
Supported
Video Output
HDMI Output
1-ch: 1920 × 1080 / 60Hz,
1280 × 1024 / 60Hz, 1280 × 720 / 60Hz
VGA Output
1-ch: 1920 × 1080 / 60Hz,
1280 × 1024 / 60Hz, 1280 × 720 / 60Hz
Video Output Mode
HDMI / VGA simultaneous output
Audio
Audio Input
4-ch RCA (2.0 Vp-p, 1 KΩ), 4-ch via coaxial cable
1-ch (up to 4-ch optional), RCA
Audio Output
1-ch RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch RCA (using the first audio input)
Playback
Synchronous Playback
4-channel simultaneous playback
