Advanced AI DVR designed for professional surveillance, featuring facial recognition and detection, Motion Detection 2.0, perimeter protection, and powerful IP expansion with 4K video output support.
Product Specifications
AI & Smart Features
Facial Recognition
Face picture comparison and face picture search
(4-ch face picture comparison alarm for HD analog cameras)
Face Picture Library
Up to 16 face picture libraries
Face library data is protected—HDD damage will not cause data loss as the library is backed up by HDD and flash
Facial Detection
Facial detection and capture
Face picture detection and search
4-ch face picture capture
Motion Detection
Motion Detection 2.0 (Deep Learning)
Human / Vehicle Analysis
Intelligent classification to significantly reduce false alarms caused by leaves, lights, and other disturbances
Quick Search
Search by object or event type
Perimeter Protection
Human / vehicle analysis, up to 8 channels (advanced model)
Video & Audio Input
IP Video Input
8-ch (up to 24-ch), up to 6 MP resolution
Analog Video Input
16-ch, BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported
HDTVI Input
3K@25/20 fps, 2K@20 fps, 5 MP@20 fps,
4 MP@25/30 fps, 1080p@25/30 fps, 720p@25/30 fps
AHD Input
5 MP@20 fps, 4 MP@25/30 fps,
1080p@25/30 fps, 720p@25/30 fps
HDCVI Input
3K@20/25 fps, 5 MP@20 fps, 4 MP@25/30 fps,
1080p@25/30 fps, 720p@25/30 fps
CVBS Input
PAL / NTSC
Video Output
HDMI Output
1-ch: 4K (3840 × 2160) @30Hz,
2K (2560 × 1440) @60Hz,
1920 × 1080 @60Hz,
1280 × 1024 @60Hz,
1280 × 720 @60Hz
VGA Output
1-ch: 1920 × 1080 @60Hz,
1280 × 1024 @60Hz, 1280 × 720 @60Hz
CVBS Output
1-ch BNC (1.0 Vp-p, 75 Ω)
PAL: 704 × 576 / NTSC: 704 × 480
Video Output Mode
HDMI / VGA simultaneous output
Audio
Audio Input
1-ch (up to 16-ch optional), RCA (2.0 Vp-p, 1 KΩ)
16-ch via coaxial cable
Audio Output
1-ch RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch RCA (using the first audio input)
Playback
Synchronous Playback
16-channel simultaneous playback
