Enterprise-grade 16-channel AI DVR featuring advanced facial recognition, Motion Detection 2.0, perimeter protection, and powerful IP expansion with 4K HDMI output—built for large-scale intelligent surveillance deployments.
Product Specifications
AI & Smart Features
Facial Recognition
Face picture comparison and face picture search
(4-ch face picture comparison alarm for HD analog cameras)
Face Picture Library
Up to 16 face picture libraries
Face library data is protected—HDD damage will not cause data loss as the library is backed up by HDD and flash
Motion Detection
Motion Detection 2.0 (Deep Learning)
Human / Vehicle Analysis
Intelligent classification of humans and vehicles to greatly reduce false alarms caused by leaves, lights, and environmental interference
Quick Search
Search by object or event type
Perimeter Protection
Human / vehicle analysis, up to 8 channels (advanced model)
Facial Detection
Facial detection and capture
Face picture detection and face picture search
4-ch face picture capture
Video & Audio Input
IP Video Input
8-ch (up to 24-ch), each up to 6 MP resolution
Analog Video Input
16-ch, BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported
HDTVI Input
3K@25/20 fps, 2K@20 fps, 5 MP@20 fps,
4 MP@25/30 fps, 1080p@25/30 fps, 720p@25/30 fps
AHD Input
5 MP@20 fps, 4 MP@25/30 fps,
1080p@25/30 fps, 720p@25/30 fps
HDCVI Input
3K@20/25 fps, 5 MP@20 fps, 4 MP@25/30 fps,
1080p@25/30 fps, 720p@25/30 fps
CVBS Input
PAL / NTSC
Video Output
HDMI Output
1-ch: 4K (3840 × 2160) @30Hz,
2K (2560 × 1440) @60Hz,
1920 × 1080 @60Hz,
1280 × 1024 @60Hz,
1280 × 720 @60Hz
VGA Output
1-ch: 1920 × 1080 @60Hz,
1280 × 1024 @60Hz, 1280 × 720 @60Hz
CVBS Output
1-ch BNC (1.0 Vp-p, 75 Ω)
PAL: 704 × 576 / NTSC: 704 × 480
Video Output Mode
HDMI / VGA simultaneous output
Audio
Audio Input
1-ch (up to 16-ch optional), RCA (2.0 Vp-p, 1 KΩ)
16-ch via coaxial cable
Audio Output
1-ch RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch RCA (using the first audio input)
Playback
Synchronous Playback
16-channel simultaneous playback
